HomeProduct CenterThermal Conductivity > Liquid Thermal Conductivity Meter > TC3200L High-Temperature Thermal Conductivity Meter

Return

TC3200L High-Temperature Thermal Conductivity Meter

A high-precision instrument specifically developed for measuring the thermal conductivity of liquids under high-temperature conditions, with a test temperature up to 200℃ and pressure resistance of 15 MPa.

Product features:: Fluid-specific measurement：Hot Wire Method; Rapid measurement: data acquisition within 2 seconds; Highly automated: Sampling/ control/acquisition/ sample discharg

Description Technical Parameter Product Application

Description

The TC3200L High-Temperature Liquid Thermal Conductivity Meter is a high-precision instrument specially developed for liquid thermal conductivity measurement. Employing the transient hot-wire technique, it measures liquid thermal conductivity within the temperature range of ambient +10~200℃ and withstands pressure up to 15MPa. It features fast testing, high accuracy, high automation, and easy operation. Its professional structural design ensures sufficient shock resistance and durability, requiring only a small sample volume (30 mL) to obtain accurate and reliable thermal conductivity data. It is suitable for measuring thermal conductivity of liquids under different temperature/pressure conditions, such as lubricating oils, nanofluids, refrigerants, liquid fuels, fluorinated liquids, and coolants.

Key Features

l Fluid-specific measurement: Adopting the transient hot-wire method, a reliable approach for liquid thermal conductivity testing;

l Fast measurement: Acquisition time ≤ 2s, effectively avoiding convection to ensure measurement accuracy.

l Wide temperature range: Capable of measuring thermal conductivity within ambient +10~200℃.

l Broad pressure resistance: Withstanding up to 15MPa, enabling acquisition of thermal conductivity-pressure data.

l Small sample volume: Only 30~40 mL of sample is needed for reliable results.

l High automation: Automatic sampling and draining, automatic temperature control and measurement, automatic pressure control and measurement, as well as automatic data processing.

l Wide applicability: Suitable for measuring thermal conductivity of liquids under different temperature/pressure conditions, including lubricating oils, nanofluids, refrigerants, liquid fuels, fluorinated liquids, and coolants.
