Engineered for measuring gases and low-temperature liquefiable liquids, it offers a viscosity range down to 10 μPa·s and temperature measurement from -160°C to room temperature.

The XIATECH VM2400 gas viscometer employs the vibrating wire method to obtain gas viscosity data, with a measurable viscosity range as low as 10 μPa·s. Its temperature measurement range spans from -160℃ to room temperature (with customization available for higher or lower temperatures), and an optional pressure module enables high-pressure measurements from 0.1 to 10 MPa. The instrument is easy to operate and features fully automated testing, including automatic temperature control, automatic pressure application, and automatic sample injection, significantly reducing labor costs. Additionally, the VM series is equipped with a hermetically sealed test chamber, which ensures the accuracy and reliability of gas measurement results, providing high-precision data for gas property research.

Key Features

l Gas measurement capability: Suitable for viscosity testing of low-viscosity media such as gases and low-temperature liquefied liquids.

l High precision and stability: Adopting the vibrating wire method, it delivers high measurement accuracy and excellent repeatability, unaffected by surface tension and interfacial tension.

l Low-temperature testing capability: Covering the range from low temperatures (-160℃) to room temperature, with support for customized temperature ranges, making it suitable for various complex working conditions.

l High-pressure measurement capability: Withstanding pressures up to 10 MPa, meeting viscosity measurement requirements under high-pressure conditions.

l Fully automated operation: Supporting functions such as automatic temperature control, automatic pressure application, and automatic sample injection, it is user-friendly and reduces labor costs.

l Hermetically sealed test chamber: Ideal for measuring volatile liquids, ensuring the safety and accuracy of the measurement process.

l Professional software support: Equipped with intuitive testing software that enables automatic data collection and analysis, facilitating users to quickly obtain reliable data.
