HomeProduct CenterViscosity > Low-Temperature Viscometer > VM2100 Viscometer

Return

VM2100 Viscometer

Covering a temperature measurement range of -30~100℃, the device is characterized by high testing precision, excellent stability, simple operation, and a high level of automation.

Product features:: Viscosity range: Optional, ensuring the reliability of measurement results; Automatic operation: Automatic sampling/control/measurement; Broad testing range: Enables the acquisition of viscosity-temperature curves / viscosity-pressure curves

Description Technical Parameter Product Application

Description

The VM2100 low-temperature viscometer utilizes the vibrating wire method to obtain viscosity data of the tested liquids. It boasts high measurement accuracy, excellent stability, and easy operation, finding wide application in the testing and research of various liquids such as refrigerants, lubricating oils, coolants, and fluorinated fluids. Its sealed chamber is particularly suitable for measuring volatile liquids, and equipped with a pressure module, it can simultaneously generate viscosity-temperature and viscosity-pressure curves.

Key Features

l High precision and stability: Adopting the vibrating string method, it delivers high measurement accuracy and good repeatability, unaffected by surface tension and interfacial tension.

l Broad temperature range: Covering -30℃ to 100℃, with support for customized temperature ranges, making it suitable for various complex working conditions.

l High-pressure measurement capability: Withstanding pressures up to 15 MPa, meeting viscosity measurement requirements under high-pressure conditions.

l Automated operation: Supporting functions sucn as automatic temperature control, automatic pressure application, and automatic sample injection, it is easy to operate and reduces labor costs.

l Hermetically sealed test chamber: Ideal for measuring volatile liquids, ensuring the safety and accuracy of the measurement process.

l Professional software support: Equipped with intuitive testing software that enables automatic data collection and analysis, facilitating users to quickly obtain reliable data.
