VM2200 Viscometer

Designed for studying the viscosity properties of liquids in high-temperature environments, it covers a temperature range from RT+10°C to 300°C and enables automatic measurement.

Product features:: High-temperature measurement: up to 300℃, meeting the needs of various high-temperature application scenarios; Automatic operation: Automatic sampling/ control/ measurement; Broad testing range: Enables the acquisition of viscosity-temperature curves / viscosity-pressure curves

Description Technical Parameter Product Application

Description

The VM2200 High-Temperature Viscometer, utilizing the vibrating wire test method, provides viscosity data of measured liquids with high accuracy, good stability, and simple operation. It is widely applied in testing and research of various liquids such as refrigerants, lubricating oils, coolants, and fluorinated liquids. Its sealed chamber is particularly suitable for measuring volatile liquids, and with a pressure module, it can simultaneously generate viscosity-temperature and viscosity-pressure curves.

Key Features

l High precision and stability: Adopting the vibrating string method, it ensures high measurement accuracy and excellent repeatability, unaffected by surface tension or interfacial tension.

l High-temperature measurement capability: Test temperature up to 300℃, meeting the needs of various high-temperature application scenarios, with support for custom higher temperatures.

l High-pressure measurement capability: Pressure resistance up to 15 MPa, satisfying viscosity measurement requirements under high-pressure conditions.

l Automated operation: Supporting automatic temperature control, pressure adjustment, and sample injection for easy operation and reduced labor costs.

l Sealed test chamber: Suitable for measuring volatile liquids, ensuring safety and accuracy during the measurement process.

l Professional software support: Equipped with user-friendly testing software that enables automatic data collection and analysis, facilitating quick access to reliable data.
