It is suitable for measuring high saturated vapor pressure samples within the temperature range of -30~100℃, with a maximum pressure of 5MPa and optional pressure ranges.

The VP2100 High-Pressure Vapor Pressure Tester is a fluid saturated vapor pressure testing device launched by XIATECH specifically for high-pressure measurement in medium to low-temperature environments. It enables experimental measurements within the 5MPa pressure range under medium to low-temperature (-30~100℃) control. The device can be optionally equipped with pressure sensors of different ranges (500kPa, 1MPa, 2MPa, 5MPa, etc.) with a measurement accuracy of less than 0.1% FS. Users can select a pressure sensor with an appropriate range based on the saturated vapor pressure range of the sample to be tested, ensuring accurate and reliable results.

The device retains the advantages of the VP2000 series fully automatic vapor pressure testers, including program-controlled temperature and automatic testing functions. Users only need to set all target temperature points before testing, and the system will automatically start temperature control and gradually complete measurements at the corresponding temperature points. With high testing efficiency, it is suitable for measuring high saturated vapor pressure of various fluids, such as chemical reagents, electronic fluorinated liquids, electrolytes, lubricants, aviation kerosene, and fine chemicals.

Key Features

l High-Pressure Measurement: Maximum pressure up to 5MPa with optional ranges; higher pressure available upon customization.

l Medium to Low-Temperature Control: Temperature control range of -30~100℃ with a fluctuation of less than ±0.05℃.

l Fully Automated Control: Realizes automatic sampling, temperature control, temperature measurement, pressure measurement, and automatic data processing for high testing efficiency.

l Accurate Pressure Measurement: Uses a high-precision pressure sensor with measurement accuracy less than 0.1% FS (higher accuracy available upon customization).

l Safety Overpressure Protection: Automatic pressure relief function to prevent equipment damage from high pressure.
